IBC Bin Series Multi Functional Powder Bin Blender Blending Machine

Bin Series Multi Functional Powder Bin Blender Blending Machine

Model:
TJC Bin series

Availability:

Quantity:



Inquire Add to Basket

Product Description

Product Description

USAGE: FEATURES:

The TJC bin is used for storage, transferring, and mixing of the bulk material on their processing, and handling stage in the pharmaceutical, chemical material and food industries, etc.TJF series bin is applied to TJD series bin blender, TJT series bin is applied to the TLT series post bin blender, and TJ series bin is ideal for the transferring and storage of material. All the TJC bins could be designed & fabricated to match with stackable request for saving handling and storage space.
The TJC bin is designed with the volume ranges from 100L to 2000L, to meet the different handling and processing requirements. The bin could be designed for handling by post hoist, forklift, or manual moving operation; and could be also processed in the IBC washer, and IBC washing & drying cabinet.
The TJC bin is designed with high-strength structure, round corner without dead angle, tilting with no material left; the loading inlet port designed with silicon gasket sealing, and unloading port designed with silicon gasket sealed butterfly valve. The structure complies with the FDA standard.
The bin is made of high-quality stainless steel, with smooth welds and the internal & external surface well polished. It can also be designed in the shaping according to client`s particular application requirement.

TECHNICAL DATA:

Model	Volume V(L)	Width B(mm)	Height H(mm)	Inlet port d(mm)	Oultet port d(mm)	Weight W(kg)
TJF-400	400	800	1270	380	200	165
TJF-600	600	1000	1320	380	200	195
TJF-800	800	1000	1520	380	200	210
TJF-1000	1000	1200	1515	380	250	259
TJF-1200	1200	1200	1665	380	250	295
TJF-1500	1500	1200	1875	380	250	322
TJF-1800	1800	1200	2095	380	250	340
TJF-2000	2000	1200	2235	380	250	365

Model	Volume V(L)	Width B(mm)	Height H(mm)	Inlet port d(mm)	Oultet port d(mm)	Weight W(kg)
TJT-100	100	500	858	200	150	115
TJT-200	200	700	978	380	200	135
TJT-300	300	700	1178	380	200	155
TJT-400	400	800	1248	380	200	165
TJT-600	600	900	1424	380	200	195
TJT-800	800	1000	1484	380	200	210
TJT-1000	1000	1100	1544	380	200	259
TJT-1200	1200	1100	1704	380	200	310
TJT-1500	1500	1100	1976	380	200	335

Model	Volume V(L)	Width B(mm)	Height H(mm)	Inlet port d(mm)	Oultet port d(mm)	Weight W(kg)
TJ-150	150	700	971	380	200	115
TJ-200	200	700	978	380	200	120
TJ-300	300	800	1098	380	200	143
TJ-400	400	800	1248	380	200	150
TJ-500	500	1000	1208	380	200	158
TJ-600	600	1000	1308	380	200	165
TJ-800	800	1000	1508	380	200	190
TJ-1000	1000	1200	1511	380	200	230

Model	Volume V(L)	ØD	H	h	M
TJL-100	100	490	530	430	590
TJL-150	150	590	550	450	690
TLT-200	200	700	520	420	800
