TJＡ Series Multi-Directional Motions Mixer

Usage:

TJＡ Series multi-directional motions mixer is a novelty material mixer ,which is extensively used in Pharmacy 、 Chemical industry、Metallurgical Industry、Food、Light industry 、Agriculture and so on,. The machine can mix powder or granules very evenly, so that the mixed materials can reach their best effect.

Features:

1 It has a unique driven shaft buffer mechanism, so that the whole machine runs stably and reliably with low noise.

2 The equipment does not need a foundation and features convenient erection and maintenance as well as long service life。

3 It can ensure a good mixing effect and short minxing time. The evenness of mixing reaches above 99.5%；

4 Its charge coefficient reaches 85%， more than double that of an ordinary rotary mixer.

Working principle:

The mixing barrel is supported by the driving and driven shafts which are crossed in space and also vertical to each other, and are respectively connected by Y-type universal joints, so that the mixing barrel makes unique translation, turning, turning over motions in Three-dimensional space, thereby speeds up the flow and diffusion of the materials being mixed, while avoids the specific gravity segregation of materials due to the action of centrifugal force in an ordinary mixer, and ensures the materials to reach an ideal mixing within a short time
