Features
1. The injector is heated by water-bathing (not heating tube), which keeps the temperature of the injector more stable to improve the capsule seam absolutely, and reduces the problem of uneven capsule.
2. Automatic Filling Volume Adjustment System
Medicine loading time and quantity can be adjusted automatically using touch screen during operation, which is more accurate and save more time .
3. The main shaft left and right holes are machined by using the boring mill imported from Switzerland, so that the runout and parallelism of the left and right main shafts are up to the international advanced level.
4. Micro-lubricant technology to reach cleaning-free of soft capsule.
5. The compulsory cold air system is designed at two sides of soft capsule outlet area. Thus, the net gelatin wont be around the pill dropping unit.
6. The pill-pressing operation process is simple and reliable due to the use of pneumatic clamping system. Also, there is a pressure gauge.
7. Electric-driven lifting injector unit can stop at any position as needed to reduce the labor intensity of workers.
8. Synchronism system design is applied, which greatly reduces the noise of whole equipment.
9.Patented hydro-cooling technique is applied to cool the gelatin, which avoid dew condensation problem that affect the formation of soft capsule on running pulley under high temperature and high humidity environment.
10.The PLC and touch screen from the Siemens is adopted for the electronic control system. All frequency converters are from Siemens; all relays are from ABB; all plug-socket components are from Weidmuller. Therefore, the electronic control system is more stable and durable
Main Technical Data:
| Dimension | 2100x1000x1900mm(LxWxH) |
| Weight | 1500kg |
| Power | 12Kw,380V/60Hz/3Ph(can be modified as needed) |
| Plunger Qty | 20 plungers |
| Filling Volume | 0-2ml |
| Filling Precision | ±0.5%(Oil)±1.5%(Suspension) |
| Die Roll Size | φ150x250mm |
| Die Roll Speed | 5RPM(Maximum) |
| Output (20#OB) | 42840 per hour(3RPM) |
